Description
Features/Specifications
- Microplate Capacity: Standard 6-, 12-, 24-, 48-, 96-, 384-well microplates
- Max Plate Height: Luminescence/Fluorescence modes: plates up to 1.25” (31.75 mm) high Absorbance mode: plates up to 0.8” (20.30 mm) high
- Light Source: Absorbance: Xe flash light source; Fluorescence: Tungsten quartz halogen
- Power Consumption: 100 VA max, 130 VA max with injectors
- Incubation: Temperature control range from 4º over ambient to 50ºC; Temperature variation ± 0.50°C across the plate @ 37°C (250 µL per well with the plate sealed)
- Plate Shaking: Low, Medium, High and Variable shaking speeds. Shake time is programmable by the user
- Read Modes: Normal, Rapid and Sweep
- Absorbance Measurement Range: 0.000 to 4.000 OD
- Absorbance Accuracy: 2.000 to 2.500 OD ± 3.0% ± 0.010 OD Normal and Rapid modes, 96- and 384-well plates
- Absorbance Linearity: 2.000 to 2.500 OD ± 3.0% Normal and Rapid modes, 96- and 384-well plates
- Absorbance Repeatability: 0.000 to 2.000 OD ± 1.0% ± 0.005 OD Normal and Rapid modes, 96- and 384-well plates
- Fluorescence Read Timing: Excitation Filter: 485/20 nm; Emission Filter: 528/20 nm; 96-well read: 89 sec; 384-well read: 275 sec
- Fluorescence Sensitivity: 5mm probe: 10 pg/ml solution of Sodium Fluorescein in PBS; 3mm probe: 20 pg/ml solution of Sodium Fluorescein in PBS; 1.5mm probe: 40 pg/ml solution of Sodium Fluorescein in PBS
- Time Resolved Fluorescence: Delay 0 or 20 µs to 16000 µs; Integration interval 20 to 16000 µs; Times adjustable in 10 µs increments
