Description
- The Flexicon PD121 is a versatile peristaltic pump designed for precise fluid filling and dispensing, offering a wide range of features and capabilities. It boasts high accuracy, with filling accuracies better than +/- 0.5% for fills above 0.5 ml and +/- 1% for fills below 0.5 ml. The pump can dispense volumes from 0.01 to 9999.9 ml, with a flow rate of 850 to 4200 ml/min depending on viscosity.
- Tube Sizes: 0.5, 0.8, 1.2, 1.6, 3.2, 4.8, 6.0, and 8.0 mm i.d.
- Tube Material: Watson-Marlow Flexicon peroxide or platinum-cured silicone tubes.
- Pump Head: Quick-change peristaltic head in anodized aluminum.
- Power Consumption: Max. 150 W.
- Ingress Protection: IP54.
- Interface: RS-485 multi-drop network, 1 x (5-50 VDC) input for start.
- Programming: User-programmable “recipes” for defining filling parameters.
- Calibration: Requires recalibration when changing volume, tube size, or velocity.
- 115V 60Hz 150W
