Description
- 96-well plate processing: <15 mins (with 2 sec acquisition)
- Carryover %: <0.5%
- Aspirated sample volume: 2 to 10uL
- Supported plate formats: standard 96-well and 384-well flat bottom microtiter plates
- Sample mixing system: automated pre-acquisition mixing per well
- Volume: 5 to 100uL
- Speed: 25 to 250uL/s
- Mix cycles: 0 to 5 times per well
- Flow rates: continuously adjustable sample flow rates ranging from 12 to 60 uL/min
- Probe wash volume: programmable between 200 and 800uL to minimize inter-well contamination
- Max cell density: for ideal fluidics operation, cell concentrations should not exceed 6 x 10^6 cells/mL in a 250uL sample volume
- Dimensions: 14″x12″x16″
