Description
- Syringe capacity: natively holds 1 or 2 syringes simultaneously
- Syringe sizes accepted: natively accommodates syringe sizes ranging from 0.5uL to 140mL
- Flow rate range: highly flexible volume pacing stretching from 3.06 pL/min up to 215.8mL/min (depending on the installed syringe diameter)
- Flow accuracy: ±0.35%
- Linear force output: delivers up to 75lbs / 34kg of high torque linear force to handle highly viscous process fluids
- 4.3″ color TFT graphic display
- Operational modes: supports manual infusion-only, withdrawal-only, or fully automated multi-step infusion/withdrawal custom programmed script profiles
- Orientation flexibility: Rugged mechanical chassis design permits stable layout placement in either a horizontal bench configuration or turned vertically on its end to save hood footprint space
- Dimensions: 10″W x 11″D x 6.5″H
- 100-240VAC 50/60Hz
