Description
- Single channel brightfield microscopy
- 5 megapixels camera with 2.5x optical magnification
- Fast full autofocus
- Field of view: 2.15mm x 1.62mm (3.48mm²)
- Processing time: 10 to 15 seconds per sample run
- Cell size range: 7-60um for accurate cell viability: particle/aggregates down to 4um can be counted
- Required sample volume: 10uL loaded into the slide chamber
- Dilution correction: operates as integrated firmware loop that automatically multiplies results by 2x to correct for a standard 1:1 Trypan Blue dilution profile
- Dimensions: 9.5″W x 6.5″D x 9.5″H
- 100-240VAC 50/60Hz
- Cell concentration range: 1 × 10⁴ to 1 × 10⁷ cells/mL
