Description
- Brand new!
- Max throughput: Run 1 to 4 precast midi gels simultaneously
- Gel dimensions: accommodates standard midi gel sizes of 8 x 13cm inside cassette physical parameters of 10.3 x 15cm (1.0mm thickness)
- Compatible gel families: specifically optimized for all invitrogen precast midi gels (including NuPAGE Bis-Tris, NuPAGE Tris-Acetate, and Bolt gels) or empty midi-gel cassettes for manual pours
- Max input voltage: 600VDC
- Max power threshold: 200W
- Electrode configuration: pure platinum wire electrodes coupled with gold-plated copper core connections
- Operating ambient temp: 4C to 40C
- Upper buffer chamber: requires 175mL of running buffer per individual gel lane
- Lower buffer chamber: requires 700mL of total running buffer when fully populated with 4 gels
- Buffer efficiency: reengineered fluid paths utilize up to 35% less running buffer volume per gel cassette compared to legacy midi-tank designs
- Dimensions: 7.5″L x 8.35″W x 6.3″H
