Pall Integrity Test Instrument FFS02 AM

$1,495.00

Pall’s FFS02 AM Test Instrument delivers unmatched integrity testing. Advanced technology for comprehensive filter analysis. Find it at BaneBio.

1 in stock

SKU: 240068 Category:

Description

  • The Pall Corporation High Flow Palltronic Flowstar Model FFS02 is a flow measurement instrument designed for precise, accurate measurement of large volumes of fluids, making it ideal for applications in pharmaceutical, biotechnology, food and beverage production, and many other sectors.
  • High accuracy measurement and highly precise readings
  • Holds up to 160 different programs
  • User-friendly interface
  • Robust construction for long-lasting performance
  • Capacity: 160 programs
  • Test Result Capacity: 100 tests
  • Language options: English, French, German, Italian, Spanish
  • Accuracy forward flow test: +/- 3% or +/- 0.05 mL / min, whichever is the greater
  • Accuracy water intrusion test: +/- 3% or +/- 0.02 mL / min, whichever is the greater
  • Measuring range forward flow test: 0.1 – 200 mL / min
  • Measuring range water intrusion test: 0.05 – 50 mL / min
  • Measuring range water bubble point test: 300 – 6500 mbar
  • Resolution forward flow test: 0.1 mL / min
  • Resolution water intrusion test: 0.01 mL / min
  • Resolution bubble point test: 50 mbar
  • Calibration limits flow measurement: +/- 3% of measurement
  • Calibration limits pressure measurement:  +/- 0.33% of full scale
  • Flow range: 0.01 – 60 mL / min 1000 mbar
  • Flow range: 61 – 120 mL / min 1500 mbar
  • Flow range: 121 – 200 mL / min 2000 mbar
  • High flow range: 0.01 – 200 mL / min 1000 mbar
  • High flow range: 201 – 1000 mL / min 2000 mbar
  • High flow range: 1001 – 1500 mL / min 3000 mbar
  • High flow range: 1501 – 2000 mL / min 4000 mbar
  • Test pressure range: 50 – 6500 mbar
  • Dimensions: 14.4″ W x 14.6″ D x 6.3″ H (36.5 x 37 16 cm)
  • Weight: 21.6 lbs. (9.8 kg)

Additional information

Weight 50 lbs
Dimensions 17 × 17 × 13 in
